Oxford Advance Folding Mobile Hoist – Home and Care Rental

Maximum User Weight: 155kg (24 stone)

The Oxford Advance Folding Mobile Hoist is a versatile and reliable solution for home use or compact care facilities where space is at a premium. Its innovative tool-free folding design allows for easy storage and transportation, making it ideal for environments with limited space.

Safe and Comfortable Transfers

The hoist features a swan neck leg design, allowing seamless access around wider obstacles such as large chairs, commodes, or wheelchairs. A user-friendly handset provides smooth and gentle lifting, prioritising the comfort and safety of the person being transferred. Well-positioned castors with secure rear brakes give excellent manoeuvrability and stability for caregivers during use.

Practical and Durable Design

The oversized, ergonomically designed push handle allows effortless movement, reducing strain for caregivers. The integrated Smart Monitor control system keeps track of the hoist's activity, ensuring timely maintenance and consistent performance. Lightweight yet robust at 31.7kg, the hoist is easy to manoeuvre and store when folded.

Specifications:

• Maximum Overall Length: 1300mm (51 inches)
• Minimum Overall Length: 1250mm (49 inches)
• Maximum Overall Height: 1860mm (73 inches)
• Minimum Overall Height: 1360mm (53 inches)
• Maximum Spreader Bar Height: 1690mm (66 inches)
• Minimum Spreader Bar Height: 390mm (15 inches)
• Spreader Bar Height at Maximum Reach: 1170mm (46 inches)
• Spreader Bar Reach at Maximum Height: 650mm (25 inches)
• Spreader Bar Reach at Minimum Height: 350mm (13 inches)
• Maximum Reach: 835mm (32 inches)
• Turning Radius: 1420mm (56 inches)
• External Width (Legs Open): 1080mm (42 inches)
• Internal Width (Legs Open): 1000mm (39 inches)
• External Width (Legs Closed): 670mm (26 inches)
• Internal Width (Legs Closed): 570mm (22 inches)
• Overall Leg Height: 115mm (4 inches)
• Ground Clearance: 30mm (1 inch)
• Front Twin Castors Diameter: 75mm (3 inches)
• Rear Braked Castors Diameter: 100mm (4 inches)
• Battery: 1 x 24 volt rechargeable
• Battery Capacity: 3.2 Ampere hours
• Hoist Weight: 31.7kg (69.7 lb)
• Maximum User Weight: 155kg (24 stone)

Key Features:

• Tool-free folding design for effortless storage and transportation
• Swan neck leg design for easy access around wider obstacles
• Well-positioned castors with secure rear brakes for stability
• Ergonomically designed push handle for easy manoeuvring
• Smooth and gentle lifting for user comfort and safety
• Capable of accommodating a wide range of lifting needs
• Integrated Smart Monitor system for maintenance tracking
• Lightweight yet robust construction for easy handling
• Ideal for home use or compact care facilities

The Oxford Advance Folding Mobile Hoist combines versatility, ease of storage, and safe, comfortable transfers, making it a practical and reliable solution for both domestic and care environments.
